TES Vibration Monitor

Specifications

• ±125°/s Z-axis angular rate measurement range
• ±2g 3-axis acceleration measurement (XYZ) range
• Up to 330 mm/s 40°C…+85°C operating range
• 12V supply voltage
• Ethernet digital interface
• Extensive self diagnostics features
• Proven capacitive 3D-MEMS technology
• Output data rate up to 5000 Hz, recommended 2300 Hz
• Internal datalogger with ARM microprocessor
• SD card for event recording. Up to 128Gb
• IP65 Aluminum enclosure with flanges to bolt it down to rock or concrete
• With an external modem can send automatically the event data to an FTP server.
